EVGA SuperNOVA 750 G3 – 80 Plus Gold 750W

  • Unbeatable EVGA 10 Year Warranty and unparalleled EVGA Customer Support

  • 80 PLUS Gold certified, with 90% (115VAC) / 92% (220VAC~240VAC) efficiency or higher under typical loads

  • Highest quality Japanese brand capacitors ensure long-term reliability

  • Fully Modular to reduce clutter and improve airflow

  • NVIDIA SLI & AMD Crossfire Ready

  • Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection)

  • EVGA ECO Intelligent Thermal Control System eliminates fan noise at low to medium loads

  • Hydraulic Dynamic Bearing Fan for ultra-quiet operation and increased lifespan.

Cable Length

ATX Cable 1x 600mm
EPS Cable 2x 700mm
PCIe Cable 2x 700mm, 2x 700mm, 850mm
SATA Cable 3x 550mm, 650mm, 750mm
Four-Pin Peripheral Cable 1x 550mm, 650mm, 750mm, 850mm
Floppy Adapter 1x 100mm
AC Power 1x 1500mm
Modular Cable Type Full

Connector Quantity

24 Pin ATX 1x
EPS (CPU) 2x 8pin (4+4)
PCIe 6x 8pin (6+2)
SATA 9x
Four-Pin Peripheral 4x
Floppy 1x

Power Specs

AC Input 100 – 240 VAC, 10A, 50 – 60 Hz
Rail +3.3V +5V +12V +5Vsb -12V
Max Output 24A 24A 62.4A 3.0A 0.5A
748.8W
120W 748.8W 15W 6W
Total 750W @ +50C

Additional Details

Operating Temperature 0° to 50° C
Japanese Capacitors 100%
ECO Mode Yes
MTBF 100,000 Hours
Net Weight 5.60 lbs
Size 85mm (H) x 150mm (W) x 150mm (L)
Approvals CB, CE, FCC, RCM, WEEE, RoHS
Compliance with ErP Lot 6 2013 Requirement
Fan Size / Bearing 130mm Hydraulic Dynamic Bearing
